| Secondary Current (Amp) | 25 |
| Model No | SD42-05KH |
| Type of Product | Power Transformer |
| Applicable Standard | JIS C-5310/6436 |
Secondary Current (Amp) |
25 |
Model No |
SD42-05KH |
Type of Product |
Power Transformer |
Applicable Standard |
JIS C-5310/6436 |
Country of Origin |
Japan |
Shape |
TP |
Dimension B (Φmm) |
(Installation) 145 |
Specifications |
Duplex, with electrostatic shield |
Terminal Screw |
M5 |
Monotaro ID |
73427892 |
No. of Phases |
Single-Phase |
Mass (Kg) |
34.5 |
Temperature Rise |
120 ℃ or less |
Name of Manufacturer/Packer/Importer |
Toyosumi Power Equipment Co., Ltd. |
Operation Ambient Temperature (°C) |
-10 to 40 |
Import Country |
Direct Import from Japan |
Insulation Type |
H |
Outer Dimension H (mm) |
226 |
Outer Dimension d (mm) |
226 |
Outer Dimension W (mm) |
206 |
Capacity (Kva) |
5 |
Frequency (Hz) |
50/60 |
Insulation Resistance (MOhm) |
over 100 |
Mounting Screw |
M6 |
Terminal Spacing |
13.5 mm |
Mounting Dimensions (mm) |
130x145 |
