| Capacity (VA) | 1000 |
| Secondary Current (Amp) | 10 |
| Model No | CD120-10S |
| Type of Product | Power Transformer |
Capacity (VA) |
1000 |
Secondary Current (Amp) |
10 |
Model No |
CD120-10S |
Type of Product |
Power Transformer |
Outer Dimensions |
99x160x150 mm |
Applicable Standard |
JIS C-6436 |
Country of Origin |
Japan |
Shape |
CDS |
Specifications |
Single roll, no electrostatic shield |
Monotaro ID |
73427427 |
Depth |
160 mm |
No. of Phases |
Single-phase |
Mass (Kg) |
2.7 |
Temperature Rise |
80°C or less |
Protection Devices |
protector |
Name of Manufacturer/Packer/Importer |
Toyosumi Power Equipment Co., Ltd. |
Operation Ambient Temperature (°C) |
-10 to 40 |
Import Country |
Direct Import from Japan |
RoHS Directive |
Correspondence |
Insulation Type |
B |
Capacity (Kva) |
1 |
Frequency (Hz) |
50/60 |
Insulation Resistance (MOhm) |
over 100 |
Output Voltage (V) |
100 |
Input Voltage (V) |
115 to 120 |
Height H (mm) |
150 |
