Ships within 25 days
View
View
View
View
| Capacity (VA) | 2k |
| Secondary Current (Amp) | 20 |
| Voltage | Primary voltage 200/208/220/230/240 V |
| Model No | UEE0200-016015-08M(No.42957)2kVA |
Capacity (VA) |
2k |
Secondary Current (Amp) |
20 |
Voltage |
Primary voltage 200/208/220/230/240 V |
Model No |
UEE0200-016015-08M(No.42957)2kVA |
Type of Product |
Power Transformer |
Country of Origin |
Japan |
Terminal Screw |
(1st / 2nd) M4, (Ground) M4 |
Monotaro ID |
73429125 |
Mass (Kg) |
24 |
Name of Manufacturer/Packer/Importer |
Toyosumi Power Equipment Co., Ltd. |
Import Country |
Direct Import from Japan |
RoHS Directive |
Correspondence |
Mounting Dimension A (mm) |
86 |
Insulation Type |
Class F |
Mounting Dimension B (mm) |
84 |
Outer Dimension H (mm) |
110 |
Outer Dimension b (mm) |
102 |
Outer Dimension a (mm) |
99 |
Recommended Screw |
(Mounting) M6 |
Model Name |
UEE0200-016015-08M |
