| Rated Operating Current (A) | InchingA / Plugging (AC-4): (200 to 240V) 150A / (380 to 440V) 150A, 3-Phase Squirrel Cage Motor (AC-3): (200 to 240V) 180A / (380 to 440V) 180A, Resistive Load (AC-1): (200 ~ 240V) 260A / (380 ~ 440V) 260A |
| Auxiliary Contacts | 2a2b |
| Monotaro ID | 7237894 |
| Frame | N8 Type |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Rated Operating Current (A) |
InchingA / Plugging (AC-4): (200 to 240V) 150A / (380 to 440V) 150A, 3-Phase Squirrel Cage Motor (AC-3): (200 to 240V) 180A / (380 to 440V) 180A, Resistive Load (AC-1): (200 ~ 240V) 260A / (380 ~ 440V) 260A |
Auxiliary Contacts |
2a2b |
Monotaro ID |
7237894 |
Frame |
N8 Type |
Type of Product |
Electromagnetic Contactor |
Opening / Closing Frequency (times/hour) |
1200 times/hour |
Electromagnet Capacity (VA), When Turned ON |
200V 50Hz：200/200VA, 220V 60Hz：255VA (When Turned ON) |
Closed Way Current (A) |
3-Phase Squirrel Cage Motor (AC-3) 220V: 2160A, 440V: 2160A |
Electromagnet Capacity (VA), at Storage |
200V 50Hz：5.4/200VA, 220V 60Hz：6.2VA (at Storage) |
Mounting Screw |
4-M6 |
Mechanical Durability |
5 million times |
Electrical Durability |
1 million times (AC-3) |
Standard |
Overseas standards: IEC, EN, VDE, BS, UL, CSA certified |
Coil Voltage |
AC 200 V |
Model No |
SC-N8 Coil 200V 2a2b |
Thickness |
174 mm |
Length |
209 mm |
Weight |
4.9 Kg |
Breaking Current |
Three-phase squirrel-cage motor (AC-3) 220V: 1800 440V: 1800 |
Width |
138 mm |
Model Name |
SC-N8 |
Case Included |
No |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co Ltd |
