Ships within 25 days
View
View
View
View
| Monotaro ID | 50235744 |
| Frame | N4 Type |
| Type of Product | Electromagnetic Contactor |
| Mechanical Durability | 2.5 million times |
Monotaro ID |
50235744 |
Frame |
N4 Type |
Type of Product |
Electromagnetic Contactor |
Mechanical Durability |
2.5 million times |
Electrical Durability |
1 million times |
Coil Voltage |
AC 100 V |
Import Country |
Direct Import from Japan |
Model No |
SC-N4/SF Coil AC100V |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Frequency (kHz) |
3-10 |
Connector |
No connection plate |
Type of Resetting |
Manual |
Rated Coil Voltage |
AC 100 V |
Capacity |
Capacity [kvar]: 37/31 (440V), 46/38 (550V) [Capacitor switching application (connection a)] / 96/80 (800V) [Capacitor switching application (connection b)] |
Working Current |
85, 70 Amp (440V), 85, 70 Amp (550V) [Capacitor switching application Amp (connection a)] / 120, 100 Amp (800V) [Capacitor switching application Amp (connection b)] |
Dimension H (Φmm) |
Main terminal: 64 |
Mounting Dimensions (mm) |
D：70 |
Dimension L (mm) |
Main terminal: 6-M6 |
Dimension M |
Main terminals: 4 mm |
Dimension K |
Main terminal: 74 mm |
Outer Dimension b (mm) |
127 |
Dimension I (mm) |
Main terminal: 111 |
Outer Dimension a (mm) |
88 |
