| Rated Operating Current (A) | Three-phase squirrel-cage motor (AC-3): (200 to 240 V) 35 / (380 to 440 V) 32, resistive load (AC-1): (200 to 240 V) 60 / (380 to 440 V) 60 |
| Width (mm) | 123 |
| Auxiliary Contacts | 2A2B |
| Type | DC Operation Type |
Rated Operating Current (A) |
Three-phase squirrel-cage motor (AC-3): (200 to 240 V) 35 / (380 to 440 V) 32, resistive load (AC-1): (200 to 240 V) 60 / (380 to 440 V) 60 |
Width (mm) |
123 |
Auxiliary Contacts |
2A2B |
Type |
DC Operation Type |
Operation method |
DC operated type |
Monotaro ID |
50297353 |
Frame |
N2 Type |
Length (mm) |
146 |
Type of Product |
Electromagnetic Switch |
Motor Capacity (kW) |
1.5 |
Thickness (mm) |
74 |
Operation Type |
Irreversible |
Main Circuit Voltage (V) |
200 |
Rated Carrying Current (A) |
60 |
Protection Class |
Without case cover |
Coil Voltage |
AC 200 V |
Model No |
SW-N2/G 200V1.5KW Coil DC200V |
Import Country |
Direct Import from Japan |
Contact Configuration |
[Auxiliary] Dual Contact |
Included Components |
2 heat elements with thermal relay |
Compatible Motor Capacity |
Three-Phase Squirrel-Cage Motor (AC-3): 7.5 kW at 200-240 V |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Type of Resetting |
Manual |
Motor Capacity |
Three-Phase Squirrel-Cage Motor (AC-3): 15 kW at 380-440 V |
