| Rated Operating Current (A) | Three-phase squirrel-cage motor (AC-3): (200 to 240 V) 18 / (380 to 440 V) 18, resistive load (AC-1): (200 to 240 V) 25 / (380 to 440 V) 25 |
| Auxiliary Contacts | 3A1B×2 |
| Monotaro ID | 50225402 |
| Frame | E04 |
Rated Operating Current (A) |
Three-phase squirrel-cage motor (AC-3): (200 to 240 V) 18 / (380 to 440 V) 18, resistive load (AC-1): (200 to 240 V) 25 / (380 to 440 V) 25 |
Auxiliary Contacts |
3A1B×2 |
Monotaro ID |
50225402 |
Frame |
E04 |
Type of Product |
Standard Electromagnetic Contactor |
Standard |
Compliance standards: IEC 60947-4-1, EN 60947-4-1, VDE 0660, JIS C 8201-4-1<br> Certified standards: UL 60947-4-1, CSA C22.2, Certification body: TUV (EN 60947-4-1) |
Operation Type |
Reversible |
Series |
SC-E04 |
Rated Carrying Current (A) |
25 |
Coil Voltage |
DC 24 V |
Model No |
SC-E04PRM/G Coil DC24V 3A1B×2 |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Rated Voltage (V) |
DC 24 |
Atmosphere |
Low levels of dust, smoke, corrosive gases, flammable gases, steam, and salt. |
Shock Resistance (m/s²) |
50 |
Installation Altitude (m) |
2000 or less |
Wiring Connections |
Round crimp terminal compatible |
Type of Terminal Fitting |
Screw Mounting, 35 mm width Top Hat Rail Mounting |
