| Coil Voltage Rating (V) | AC 100 V |
| Rated Operating Current (A) | InchingA / Plugging (AC-4): (200 to 240V) 18A / (380 to 440V) 9A, 3-Phase Squirrel Cage Motor (AC-3): (200 to 240V) 18A / (380 to 440V) 13A, Single Phase Motor (AC-3): (100V) 18A / (220V) 18A, Resistance Load (AC-1): (200-240V) 25A / (380-440V) 25A |
| Auxiliary Contacts | 1b |
| Mechanical Durability | 10 million times |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Coil Voltage Rating (V) |
AC 100 V |
Rated Operating Current (A) |
InchingA / Plugging (AC-4): (200 to 240V) 18A / (380 to 440V) 9A, 3-Phase Squirrel Cage Motor (AC-3): (200 to 240V) 18A / (380 to 440V) 13A, Single Phase Motor (AC-3): (100V) 18A / (220V) 18A, Resistance Load (AC-1): (200-240V) 25A / (380-440V) 25A |
Auxiliary Contacts |
1b |
Mechanical Durability |
10 million times |
Type |
Standard Type |
Monotaro ID |
35174011 |
Type of Product |
Electromagnetic Switch |
Electrical Durability |
1.5 million times (AC-3) |
Standard |
Overseas standards: IEC, EN, VDE, BS, UL, CSA certified |
Motor Capacity (kW) |
3.7 kW |
Mounting Screw |
2-M4 |
Applicable Rail Width (mm) |
35 mm |
Operation Type |
Irreversible |
Main Circuit Voltage (V) |
AC200 V |
Series |
SW-4-0 |
Width |
81 mm |
Length |
127 mm |
Model No |
SW-4-0 |
Weight |
0.47 Kg |
Thickness |
53 mm |
Rated Current (A) |
25 A |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co Ltd |
Weight (g) |
470 g |
