| Rated Operating Current (A) | Three-phase squirrel-cage motor (AC-3): (200 to 240 V) 26 / (380 to 440 V) 25, resistance load (AC-1): (200 to 240 V) 50 / (380 to 440 V) 50 |
| Width (mm) | 123 |
| Auxiliary Contacts | 2A2B |
| Type | DC Operation Type |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Rated Operating Current (A) |
Three-phase squirrel-cage motor (AC-3): (200 to 240 V) 26 / (380 to 440 V) 25, resistance load (AC-1): (200 to 240 V) 50 / (380 to 440 V) 50 |
Width (mm) |
123 |
Auxiliary Contacts |
2A2B |
Type |
DC Operation Type |
Operation method |
DC operated type |
Monotaro ID |
50295962 |
Frame |
N1 Type |
Length (mm) |
146 |
Type of Product |
Electromagnetic Switch |
Thickness (mm) |
74 |
Operation Type |
Irreversible |
Rated Carrying Current (A) |
50 |
Protection Class |
Without case cover |
Coil Voltage |
DC 100 V |
Model No |
SW-N1/G 7A Coil DC100V |
Import Country |
Direct Import from Japan |
Contact Configuration |
[Auxiliary] Dual Contact |
Included Components |
2 heat elements with thermal relay |
Compatible Motor Capacity |
Three-Phase Squirrel-Cage Motor (AC-3): 5.5 kW at 200-240 V |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Type of Resetting |
Manual |
Heat Element Rating (A) |
7 |
Motor Capacity |
Three-Phase Squirrel-Cage Motor (AC-3): 11 kW at 380-440 V |
