| Rated Operating Current (A) | Three-phase squirrel-cage motor (AC-3): (200 to 240) 18, (380 to 440) 18, / Resistive load (AC-1): (200 to 240) 25, (380 to 440) 25 |
| Width (mm) | 81 |
| Monotaro ID | 50225357 |
| Frame | E04 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Rated Operating Current (A) |
Three-phase squirrel-cage motor (AC-3): (200 to 240) 18, (380 to 440) 18, / Resistive load (AC-1): (200 to 240) 25, (380 to 440) 25 |
Width (mm) |
81 |
Monotaro ID |
50225357 |
Frame |
E04 |
Length (mm) |
81 |
Type of Product |
Standard Electromagnetic Contactor |
Standard |
Compliance standards: IEC 60947-4-1, EN 60947-4-1, VDE 0660, JIS C 8201-4-1<br> Certified standards: UL 60947-4-1, CSA C22.2, Certification body: TUV (EN 60947-4-1) |
Mounting Screw |
M4 |
Mass (Kg) |
330 g |
Applicable Rail Width (mm) |
35 |
Thickness (mm) |
43 |
Operation Type |
Irreversible |
Series |
SC-E04 |
Rated Carrying Current (A) |
25 |
Coil Voltage |
AC 100 V |
Model No |
SC-E04P Coil AC100V |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Atmosphere |
Low levels of dust, smoke, corrosive gases, flammable gases, steam, and salt. |
Shock Resistance (m/s²) |
50 |
Installation Altitude (m) |
2000 or less |
Wiring Connections |
Round crimp terminal compatible |
Type of Terminal Fitting |
Screw Mounting, 35 mm width Top Hat Rail Mounting |
Ambient Temperature (℃) |
-5 to 55. No condensation or freezing due to sudden temperature changes (average temperature over 24 hours must not exceed 35°C). |
