| Test Voltage | High Potential: L to G 2660 V DC for 1 Minute, L to L 1950 V DC for 1 Minute |
| Type of Product | EMI Filter |
| Temperature Range | -25°C To +85°C |
| Model No | MF 423-4-2D |
Test Voltage |
High Potential: L to G 2660 V DC for 1 Minute, L to L 1950 V DC for 1 Minute |
Type of Product |
EMI Filter |
Temperature Range |
-25°C To +85°C |
Model No |
MF 423-4-2D |
Phase |
Three |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
EMIS India |
Application |
CNC Machines, AC/DC Drives, Convertors, Elevators, HVAC, SMPS |
Operating Frequency |
50/60Hz |
Current Rating |
15 A @ 40°C |
Weight |
3 Kg |
Climatic Category |
25/85/21 |
Standard |
UL 60939-3, CSA 22.2 No.8-13 and IEC 60939 |
Overload Capacity |
135% of Rated current for 15 minutes |
Flammability |
UL 94 V-0 |
Features |
Compact, Superior Performance, Chassis mounting 3 Phase Filter, Shock proof terminals |
Operating Voltage |
Maximum Continuous: 440/520 V AC |
Termination |
41 |
Item Code |
S42D000015C |
Part No |
E100071-5 |
Terminal Type |
Shock Proof Terminal |
