| Leakage Current | 5 mA max. [DC500 V/60 Hz] |
| Type of Product | Noise Filter |
| Model No | RTAN-5050 |
| Monotaro ID | 46734441 |
Leakage Current |
5 mA max. [DC500 V/60 Hz] |
Type of Product |
Noise Filter |
Model No |
RTAN-5050 |
Monotaro ID |
46734441 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
TDK-LAMBDA |
Import Country |
Direct Import from Japan |
Rated Voltage (V) |
[AC/DC] 500 |
Mass (g) |
1120 |
Insulation Resistance (MOhm) |
100 min.[DC 500 V/1min] |
Frequency Range (MHz) |
Differential mode: 0.3 to 30 (25 dB guaranteed), Common mode: 0.6 to 10 (25 dB guaranteed) |
Withstand voltage (V) |
AC 2500， 60sec [line - earth] |
