Ships within 25 days
View
View
View
View
| Type of Product | Wire Type Linear Encoder |
| Model No | DX-025 |
| Country of Origin | Japan |
| Name of Manufacturer/Packer/Importer | MUTOH HOLDINGS CO., LTD. |
Type of Product |
Wire Type Linear Encoder |
Model No |
DX-025 |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
MUTOH HOLDINGS CO., LTD. |
Import Country |
Direct Import from Japan |
Monotaro ID |
38639553 |
Maximum Speed |
(Detection) 15 m/min |
Durability |
(Number of round trips) 1,000,000 times or more |
Effective Length (mm) |
(Wire) 250 |
Protection Class |
IP40 (electric part only) |
Mass (g) |
60 |
Storage Temperature Range |
-20 to 80℃ |
Wire Rope Diameter (Φmm) |
0.45 |
Material (Wire Part) |
SUS304 |
Operation Mode |
Open collector |
Power Consumption |
40 mA or less (with no load) |
Input Power |
DC 4.5 to 13 V |
Operating Temperature Range |
0 to 50℃ (no condensation) |
Vibration Resistance |
55Hz, 1.5mm double amplitude, 2H each in X, Y, Z directions |
Pulse Output |
25 pulses / mm |
Standard Tension (N) |
Wire / 0.29 to 0.58 (30 to 60gf) |
Connection Cable |
2m, Φ3 (untreated tip) |
Accuracy |
Distance (at 20 ° C) /±0.2/250mm + quantization error, restoration (at 20 ° C) /±0.05mm + quantization error |
Resolution (mm) |
0.01 (when multiplying by 4) |
Shock Resistance (m/s²) |
Endurance / 490 (approx. 50G) 3 times each in X, Y and Z directions |
Output Phase |
A, B phase |
