| Type of Product | Surface Resistivity Meter (With Calibration Certificate) |
| Model No | F-110-1-TA |
| Power Supply | Built-in rechargeable battery (nickel-metal hydride battery) |
| Country of Origin | Japan |
Type of Product |
Surface Resistivity Meter (With Calibration Certificate) |
Model No |
F-110-1-TA |
Power Supply |
Built-in rechargeable battery (nickel-metal hydride battery) |
Country of Origin |
Japan |
Monotaro ID |
63334986 |
Included Components |
2 electrodes, 3 connection cords (2m), 3 alligator clips, cloth scale (40cm), SD card, AC adapter (for charging), with carrying case, calibration certificate, test report, traceability chart Comes with. |
Import Country |
Direct Import from Japan |
Accuracy |
± 10% (However, ± 20% for <sup>1.00 x 10 11 Ω and above)</sup> |
Pack of |
1 Pcs |
Name of Manufacturer/Packer/Importer |
Hozan Co., Ltd. |
Mass (Kg) |
6.4 (Main body: 715 g, Electrode: 2.3 kg (1 piece)) |
Measuring_Range |
9.00 x 10 <sup>2</sup> Ω or more, 2.00 x 10 <sup>12</sup> Ω or less |
Outer Dimensions (mm) |
Electrode: 79Φ x 110 (Conductive pad part: 63.5Φ) |
Specifications |
[Judgment function range] PASS lamp lights when the threshold is within the PASS range (buzzer sound), FAIL lamp lights when the threshold is out of the range (no buzzer sound), threshold fixed 1 (wrist strap): PASS + 7.50 x 10 <sup>5</sup> Ω ≤ R ≤3.49 x 10 <sup>7</sup> Ω, fixed threshold 2 (footwear): PASS + 1.00 x 10 <sup>5</sup> Ω ≤R ≤ 9.99 x 10 <sup>7</sup> Ω, free threshold (up to 3 thresholds can be saved): PASS + (9.00 x 10 <sup>2</sup> Ω) ~ 9.99 x 10 <sup>10</sup> Ω) ≤ R ≤ (9.00 x 10 <sup>2</sup> Ω ~ 9.99 x 10 <sup>10</sup> Ω) |
Calibration Certificate |
General calibration |
Input Voltage (V) |
10V (fixed), 100V (fixed), 10V / 100V (automatic switching) (automatic switching: 100V (when the object is 1.00 x 10 <sup>6</sup> Ω or more), 10V (when the object is <sup>less than 1.00 x 10 6</sup> Ω)) ) |
Recording Media |
SD / SDHC / SDXC + memory card (up to 128GB) |
Continuous Operating Time |
About 90 minutes |
Outer Dimensions, Width W x Height H x Depth D (mm) |
Body: 135 x 68 x 236 (excluding protrusions), Carrying case: 400 x 200 x 200 |
