| Type of Product | Industrial Ethernet Switch |
| Type | LAN port: 100BASE-Tx |
| Power Consumption | 2.6 W |
| Model No | TCSESPU083FN0 |
Type of Product |
Industrial Ethernet Switch |
Type |
LAN port: 100BASE-Tx |
Power Consumption |
2.6 W |
Model No |
TCSESPU083FN0 |
Voltage |
12 to 24 V DC (9.6 to 32 V DC) SELV |
Specifications |
●Ethernet service 1: QoS, aging time, flow control, broadcast storm/threshold control, multicast storm/threshold control, port priority, link alarm, jumbo frame (9720 bytes) ●Ethernet service 2: USB 2.0 type A master mode x 1 Settings are made using the software "Unmanaged Switch Tool" and set up on the main unit via USB memory. |
Output |
Alarm relay: Outputs when either P1 or P2 power supply input is faulty, the device is not operating, or at least one port has a faulty connection (voltage-free contact, maximum 1A/24 Vdc). Can be monitored for each port (default setting). |
Connector Type |
LAN port: RJ45 |
No. of Port |
LAN ports: 8x10 |
Country of Origin |
Japan |
Cable Type |
LAN port: Shielded twisted pair, Category CAT 5E |
Name of Manufacturer/Packer/Importer |
Arrow & Harmony (Schneider Electric) |
Import Country |
Direct Import from Japan |
Monotaro ID |
79437988 |
Outer Dimensions, Width W x Height H x Depth D (mm) |
50x135x117 |
IP Grade |
IP 40 |
Ambient Humidity to Use |
10 to 95% non-condensing |
Optical Fiber |
Number of ports: None |
Operation Ambient Temperature (°C) |
-40 to +70 |
