| Type of Product | Electric Expansion Valve |
| Country of Origin | Denmark |
| Name of Manufacturer/Packer/Importer | Danfoss |
| Model No | 034G7801 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Electric Expansion Valve |
Country of Origin |
Denmark |
Name of Manufacturer/Packer/Importer |
Danfoss |
Model No |
034G7801 |
Flow Direction |
Bi-Flow |
Type |
ETS 100C |
Inlet Size |
28 mm (1.1/8 inch) |
Outlet size |
35 mm (1.3/8 inch) |
Volume |
1.651 L |
Maximum Working Pressure |
50 Bar |
IP Rating |
IP67 |
Motor Type |
Bi-Polar |
Connection Type |
Solder ODF |
Refrigerant Compatibility |
R1233zd(E), R1234ze(E), R134a, R22, R227ea, R23, R245fa, R404A, R407A, R407B, R407C, R407F, R407H, R410A, R412A, R413A, R417A, R422A, R422B, R422D, R427A, R438A, R442A, R447A, R448A, R449A, R449B, R450A, R452A, R454A, R454C, R455A, R463A, R502, R507A, R512A, R513A, R513B, R515A, R515B, R516A |
Net Weight |
33.3 g |
Temperature Range |
-40°C to 70°C |
Electrical Connections |
M12, 4-Pin (Male) |
