| Type of Product | Strong Spring |
| Model No | TH30×55 |
| Color | Green |
| Material | Silicon chrome steel for spring |
Type of Product |
Strong Spring |
Model No |
TH30×55 |
Color |
Green |
Material |
Silicon chrome steel for spring |
Country of Origin |
Japan |
Spring Type |
Strong spring |
Name of Manufacturer/Packer/Importer |
Tokyo Spring Manufacturing Co., Ltd. |
Type |
Light Load |
Import Country |
Direct Import from Japan |
Load (300000 times, N [kgf]) |
2648[270.0] |
Spring Constant (N/mm) |
200.34 |
Deflection (300,000 times, mm) |
13.2 |
Deflection (1 million times, mm) |
10.6 |
Monotaro ID |
7049411 |
Outer Diameter (Φmm) |
30 |
Operating Temperature Range |
150 to -30℃ |
Load (1 million times, N [kgf]) |
2120[216.2] |
Free Length (mm) |
55 |
Inner Diameter |
15 mm |
Load (500000 times, N [kgf]) |
2380[242.7] |
Deflection (500,000 times, mm) |
11.9 |
Trusco Part No. |
443-3378 |
