| Type of Product | Optical Fingerprint Scanner |
| Model No | FM220U |
| Operating Voltage | +5 V Tolerance 5% (USB Connector) |
| Sensor | CMOS Sensor |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Optical Fingerprint Scanner |
Model No |
FM220U |
Operating Voltage |
+5 V Tolerance 5% (USB Connector) |
Sensor |
CMOS Sensor |
Weight |
100 g (Approx) |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
ACE CONTROLTECH SYSTEM |
Interface |
Standard USB Compliant Cable |
Image Formats |
13.3 x 16.4 (mm) (H x V) |
Temperature |
0°C to 50°C (Without External Enclosure) |
Humidity |
＜90% Non Condensing |
Light Source |
Scanning: Infrared Red (940 nm) |
Dimension |
80 mm (L) x 41 mm(M) x 40 mm(H) |
Image Resolution |
500 dpi (H), 500 dpi (V) (600 dpi optional) |
Power Supply |
1 W Approx (from USB port) (200 mA, Approx, Standby: 60 mA) |
Hardware |
Minimum Requirement: P3 800 MHz CPU or up, 256 MB, USB2.0 |
Gray Level |
8 Bits/pixel, Max 256 Gray Scales |
Output Size |
264 x 324 pixels (H x V) |
Compliance |
CE, FCC |
ESD |
15 KV |
Time |
Scanning: 1/15 second |
Distortion |
<1% |
Ratio |
Image Ratio = 1:1 |
