| Zone | 16 Zone |
| Construction Details | 1.8 mm CRCA sheet duly power coated |
| End of Line (EOL) Resistance | 4k7 ohm, 1 per zone |
| Weight | 4.5 Kg |
Zone |
16 Zone |
Construction Details |
1.8 mm CRCA sheet duly power coated |
End of Line (EOL) Resistance |
4k7 ohm, 1 per zone |
Weight |
4.5 Kg |
Color |
Caramel White |
Dimension |
272 x 346 x 96 mm |
Model No |
K-16ZFP |
Operating Voltage |
AC 220 V 50 Hz ±10%, DC 24 V 1 Amp |
Operating Temperature |
0 to 50 °C |
Type of Product |
Conventional Fire Alarm Panel |
Country of Origin |
India |
Operating Humidity |
95% (non-condensing) |
Name of Manufacturer/Packer/Importer |
Kartik Fire Protection |
Key Features |
• Fully complies to IS 2189 & tested by ERTL (N) • Operates on 220V AC, 50Hz AC Supply • 16*2 line dot matrix LCD • Zone wise fire, open, short LED Indications • External s/w to test each zone fire, open, short status manually • External s/w for reset, silence, lamp test • Zone isolation facility with zone voltage cutoff • Relay for free contacts • Mains on, system on, char ger on visual indications • battery low & common fire indications • Auto dialer attachable facility • Enough inside space for SMF battery • Compatible with all types of fire detectors • Maximum 25 nos. detectors in each zone • Hooter output current can be increased as per customer requirement. |
Hooter Output |
1 A (24 VDC) |
