| Cell Spacing (mm) | (Polarity slot) 22.86 |
| Monotaro ID | 8592911 |
| Suitable Wire | For pressure welding: 1.27 mm pitch flat cable AWG28 (7 stranded wires), UL2651 (standard cable), UL20012 (sudare cable), UL20028 (color code cable) |
| Shape | MIL type plug (with short lock) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Cell Spacing (mm) |
(Polarity slot) 22.86 |
Monotaro ID |
8592911 |
Suitable Wire |
For pressure welding: 1.27 mm pitch flat cable AWG28 (7 stranded wires), UL2651 (standard cable), UL20012 (sudare cable), UL20028 (color code cable) |
Shape |
MIL type plug (with short lock) |
Type of Product |
Flat Cable Connector |
No. of Pole |
40-Pole |
Housing Material |
Glass-filled PBT resin (UL94V-0) / Black |
Total Insertion Force |
40x1.96N or less |
Withstand Voltage |
500 VAC, 1 min (leakage current 1 mA or less) |
Rated Voltage (V) |
AC300 |
Number of polar slots |
1 |
Standard |
RoHS directive, ML standard (MIL-C-83503), UL standard (file No.E103202) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Terminal Shape |
DIP straight terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-55 to +105 (no freezing in the bass) |
Contact Resistance (ohm) |
20 or less (20mV or less, 100mA or less) |
Dimension A (Φmm) |
φ70.1 mm |
Dimension B (Φmm) |
φ55.6 mm |
Insulation Resistance (MOhm) |
10³ or more (at 500 VDC) |
Dimension E (Φmm) |
φ66 mm |
Manufacturer Part Number |
XG4A-4032 |
Dimension C |
48.26 mm |
Dimension d |
59.9 mm |
Dimension F (Φmm) |
φ78.5 mm |
