| Cable Type | ECO |
| Insulation Material | MPPE |
| Conductor Material | Tinned Copper |
| No of Core | 18 |
Cable Type |
ECO |
Insulation Material |
MPPE |
Conductor Material |
Tinned Copper |
No of Core |
18 |
Series |
EcoFlex PUR |
Color |
Grey |
Nominal Area |
0.78 mm2 |
Type of Product |
Control Cable |
Model No |
80039 SL005 |
Cable Length |
30 m |
Voltage Rating |
600 V |
Standard Met |
CE, CSA, UL |
Outer Diameter |
9.75 mm |
Country of Origin |
United States |
Wire Gauge |
18 AWG |
Maximum Operating Temperature |
+90°C |
Minimum Operating Temperature |
-50°C |
Conductor Resistance |
7.1 Ω/1000 ft |
Screen Type |
Unscreened |
Fire Behaviour |
Halogen Free |
Sheath Material |
PUR |
Screened or Unscreened |
Unscreened |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Core Strands |
41/0.16 mm |
Minimum Bend Radius |
4xDiameter |
