Insulation Material | PE |
Conductor Material | Tinned Copper |
No of Core | 2 |
Series | Alpha Essentials Communication & Control |
Insulation Material |
PE |
Conductor Material |
Tinned Copper |
No of Core |
2 |
Series |
Alpha Essentials Communication & Control |
Color |
Grey |
Nominal Area |
0.56 mm² |
Type of Product |
Communication Control Cable |
Model No |
2411C SL005 |
Cable Length |
30 m |
Voltage Rating |
300 V |
Standard Met |
CE, CSA, UL |
Outer Diameter |
4.67 mm |
Country of Origin |
United States |
Wire Gauge |
20 AWG |
Maximum Operating Temperature |
+75°C |
Minimum Operating Temperature |
-20°C |
Conductor Resistance |
33.46 Ω/Km |
Screen Type |
Foil |
Sheath Material |
PVC |
Screened or Unscreened |
Screened |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Core Strands |
7/0.32 mm |
Shape Type |
Round |
Wire |
Drain Wire |
Minimum Bend Radius |
10xDiameter |
Earth Cable |
No |
