| Insulation Material | PVC |
| Conductor Material | Tinned Copper |
| No of Core | Single Core |
| Series | Hook-up Wire PVC |
Insulation Material |
PVC |
Conductor Material |
Tinned Copper |
No of Core |
Single Core |
Series |
Hook-up Wire PVC |
No. of Strands |
16 |
Color |
White |
Nominal Area |
0.81 mm² |
Type of Product |
Hook Up Wire |
Model No |
3055 WH001 |
Cable Length |
305 m |
Voltage Rating |
300 V |
Standard Met |
UL Listed |
Outer Diameter |
2.01 mm |
Country of Origin |
United States |
Wall Thickness |
0.4 mm |
Wire Gauge |
18 AWG |
Maximum Operating Temperature |
+105°C |
Minimum Operating Temperature |
-40°C |
Strands |
0.25 mm |
Resistant To |
Chemicals, Oils, Solvents |
Fire Behaviour |
Flame Retardant |
Wire Style |
UL1007 |
Shield Type |
Unshielded |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Core Strands |
16/0.25 mm |
Shape Type |
Single Core |
