| Insulation Material | MPPE |
| Conductor Material | Copper |
| No of Core | Single Core |
| Series | 6820 |
Insulation Material |
MPPE |
Conductor Material |
Copper |
No of Core |
Single Core |
Series |
6820 |
No. of Strands |
7 |
Color |
Red |
Nominal Area |
0.08 mm² |
Type of Product |
Hook Up Wire |
Model No |
6820 RD001 |
Cable Length |
305 m |
Voltage Rating |
300 V |
Standard Met |
CE, ISO 6722, Reach Complaint, RoHS Complaint |
Outer Diameter |
0.79 mm |
Country of Origin |
United States |
Wall Thickness |
0.2 mm |
Wire Gauge |
28 AWG |
Maximum Operating Temperature |
+110°C |
Minimum Operating Temperature |
-40°C |
Strands |
0.12 mm |
Wire Style |
ISO 6722 |
Shield Type |
Unshielded |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Core Strands |
7/0.12 mm |
Shape Type |
Single Core |
