Ships within 30 days
Cable Length
View
View
View
View
| Cable Type | ECO |
| Insulation Material | MPPE |
| Conductor Material | Tinned Copper |
| No of Core | 6 |
Cable Type |
ECO |
Insulation Material |
MPPE |
Conductor Material |
Tinned Copper |
No of Core |
6 |
Series |
EcoCable mini |
Color |
Grey |
Nominal Area |
0.24 mm² |
Type of Product |
Mini Control Cable |
Model No |
78126 SL001 |
Cable Length |
305 m |
Voltage Rating |
300 V |
Standard Met |
CE, CSA, UL |
Outer Diameter |
3.96 mm |
Country of Origin |
United States |
Wire Gauge |
24 AWG |
Maximum Operating Temperature |
+80°C |
Minimum Operating Temperature |
-40°C |
Conductor Resistance |
24.1 Ω/1000 ft |
Screen Type |
Foil |
Fire Behaviour |
Halogen Free |
Sheath Material |
mPPE |
Screened or Unscreened |
Screened |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Core Strands |
19/0.127 mm |
Minimum Bend Radius |
10xDiameter |
Looking for bulk pricing or different specifications?
