Insulation Material | - |
Conductor Material | Annealed Copper |
No of Core | Single |
No. of Strands | 32 |
Insulation Material |
- |
Conductor Material |
Annealed Copper |
No of Core |
Single |
No. of Strands |
32 |
Color |
Black |
Nominal Area |
1 mm² |
Type of Product |
Hook Up Wire |
Model No |
2252149 |
Current Rating |
17 A |
Cable Length |
305 m |
Stranded Size |
0.2 mm |
Voltage Rating |
1 kV DC, 600 V AC |
Outer Diameter |
3 mm |
Country of Origin |
United Kingdom |
Wire Gauge |
17 AWG |
Maximum Operating Temperature |
+105°C |
Strands |
32/02 mm |
Rated |
Yes |
Fire Behaviour |
Flame Retardant |
Name of Manufacturer/Packer/Importer |
RS Component |
