| Insulation Material | PVC Insulated |
| Conductor Material | Annealed Copper |
| No of Core | 1 Core |
| No. of Strands | 84 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Insulation Material |
PVC Insulated |
Conductor Material |
Annealed Copper |
No of Core |
1 Core |
No. of Strands |
84 |
Color |
Yellow & Green |
Nominal Area |
6 Sq.mm |
Type of Product |
Hook Up Wire |
Model No |
8111473 |
Current Rating |
53 A |
Cable Length |
100 m |
Voltage Rating |
1 kV |
Standard Met |
BS6231 Type CK, CSA standard to Type TEW 105°C, UL |
Outer Diameter |
4.9 mm |
Country of Origin |
United Kingdom |
Wall Thickness |
0.8 mm |
Wire Gauge |
10 AWG |
Maximum Operating Temperature |
+105 (Air) °C, +60 (Oil) °C |
Wire Shape |
Wire |
Strands |
78/0.295 mm |
Rated |
Yes |
Name of Manufacturer/Packer/Importer |
RS Component |
