Cable Type | Airframe |
Insulation Material | Polyamide |
Conductor Material | Nickel Plated Copper |
No of Core | 1 Core |
Cable Type |
Airframe |
Insulation Material |
Polyamide |
Conductor Material |
Nickel Plated Copper |
No of Core |
1 Core |
No. of Strands |
37 |
Color |
White |
Nominal Area |
2.1 Sq.mm |
Type of Product |
Hook Up Wire |
Model No |
1113147 |
Cable Length |
100 m |
Voltage Rating |
600 V AC |
Standard Met |
EN 2084, EN 2267-009, FAR 25-869 |
Outer Diameter |
2.24 mm |
Country of Origin |
United Kingdom |
Wire Gauge |
14 AWG |
Maximum Operating Temperature |
+260°C |
Wire Shape |
Wire |
Minimum Operating Temperature |
-65°C |
Strands |
37/0.25 mm |
Fire Extinguisher Type |
Low Smoke Density |
Name of Manufacturer/Packer/Importer |
RS Component |
