Ships within 25 days
View
View
View
View
| Country of Origin | Japan |
| Type of Product | Bearing Unit UFL Type |
| Model No | UFL005E |
| Name of Manufacturer/Packer/Importer | Fujikoshi Corporation |
Country of Origin |
Japan |
Type of Product |
Bearing Unit UFL Type |
Model No |
UFL005E |
Name of Manufacturer/Packer/Importer |
Fujikoshi Corporation |
Type |
UFL-E |
Monotaro ID |
12693250 |
Dimension n (mm) |
10 |
Dimension L (mm) |
60 |
Dimensions H (mm) |
95 |
Import Country |
Direct Import from Japan |
Specifications |
With cover |
Dimension A1 |
8 mm |
Dimension A2 (mm) |
8 |
Dimensions A (mm) |
16 |
Nominal Size |
U005+ER |
Shaft diameter d1 (Φmm) |
25 |
Dimension A0 (mm) |
27.5 |
Dimension J (mm) |
75 |
Dimension B1 (mm) |
25.5 |
Dimension S |
6 mm |
Basic Rated Load Cr (kN) |
10100 |
Basic load rating Cor (N) |
5800 |
Dimension A4 (mm) |
32 |
Dimension A6 (mm) |
3 |
