| Material | Stainless steel sheet (SUS304) |
| Country of Origin | CHINA |
| Type of Product | Stainless Steel Flat Hinge (L50 X W35 X T1.5) Without Hole |
| Model No | B-1078-2 |
Material |
Stainless steel sheet (SUS304) |
Country of Origin |
CHINA |
Type of Product |
Stainless Steel Flat Hinge (L50 X W35 X T1.5) Without Hole |
Model No |
B-1078-2 |
Name of Manufacturer/Packer/Importer |
TAKIGEN MFG. CO., LTD. |
Monotaro ID |
61111916 |
TAKIGEN Code |
10682 |
Dimension L (mm) |
50 |
Surface Finish Type |
Mirror buffing |
Dimension d2 (Φmm) |
6.3 |
Dimension d1 (Φmm) |
3 |
Dimension N1 (mm) |
4 |
Dimension N2 (mm) |
3 |
Import Country |
Direct Import from Japan |
Mass (g) |
30 |
Dimension W |
35 mm |
Dimension T |
1.5 mm |
Applicable Door Height (mm) |
800 |
Door Dimensions, Height x Width (mm) |
800x400 |
Applicable Door Mass (Kg) |
8 |
Applicable Door Width (mm) |
400 |
