| Country of Origin | Japan |
| Power Supply | One AAA alkaline battery |
| Type of Product | Oxygen Detector |
| Part No | 1-8793-11 |
Country of Origin |
Japan |
Power Supply |
One AAA alkaline battery |
Type of Product |
Oxygen Detector |
Part No |
1-8793-11 |
Measurement Range |
0 to 25 vol % |
Alarm |
Buzzer, red lamp blinking, liquid crystal display, vibration |
Model No |
XO-2200 |
Indication Accuracy |
Within ± 0.5 vol% (compliant with JIS T 8201) |
Included Components |
1 AAA alkaline battery, 1 brilliant pin adapter (with mounting screws) |
Monotaro ID |
20360673 |
Continuous Operating Time |
Approx. 5,000 hours (when no alarm (gas concentration display is 20.3 vol% or more), at 20°C) |
Function |
Battery level display, peak hold function, peak value memory function, alarm functions other than gas alarm (sensor error, battery level, zero adjustment failure) |
Name of Manufacturer/Packer/Importer |
Shin-Cosmos Electric Co., Ltd. |
Concentration |
19.5vol% (1st stage), 18vol% (2nd stage) |
Import Country |
Direct Import from Japan |
Mass (g) |
Approximately 75 (including batteries) |
Type of Sample |
Diffusion type |
Response Time (seconds) |
Within 20 seconds (90% response, ambient temperature 20 ± 2 ° C) |
Dimension (WxDxH) |
65x64x22 mm (excluding protrusions) |
Operating Temperature / Humidity Range |
-10 ℃ -40 ℃, 30-90% RH or less (however, no condensation) |
Explosion-Proof Structure |
Exib II BT3 |
Target Gas |
Oxygen |
Principle |
Diaphragm galvanic cell type |
