| Type of Product | Ceramic Gauge Block Single |
| Model No | C6.0-1 |
| Material | Ceramic (Zirconia) |
| Type | Single item |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Ceramic Gauge Block Single |
Model No |
C6.0-1 |
Material |
Ceramic (Zirconia) |
Type |
Single item |
Country of Origin |
Japan |
Accuracy Grade |
First grade |
Monotaro ID |
86909347 |
RoHS Directive |
Correspondence |
Specific Gravity |
6 |
Hardness |
1350HV |
Nominal Size (mm) |
6 mm |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Mitutoyo Corporation |
Product Code |
613616-03 |
Fracture Toughness |
7MPa・m<sup>1/2</sup> |
Dimensional Tolerance (μm) |
±0.20 |
Bending Strength (MPa) |
1270 |
Dimensional Tolerance Width (μm) |
0.16 |
Height (mm) |
30 |
Thermal Expansion Coefficient (×10-7/℃) |
9.3±0.5 |
Width (mm) |
9 |
Young's Modulus (GPa) |
2.06E-2 |
Thermal Conductivity (W/mk) |
2.9 |
