| Type of Product | Rectangular Gauge Block |
| Model No | 15.0-0 |
| Material | High carbon high chromium steel |
| Type | Single item |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Rectangular Gauge Block |
Model No |
15.0-0 |
Material |
High carbon high chromium steel |
Type |
Single item |
Country of Origin |
Japan |
Accuracy Grade |
Class 0 |
Monotaro ID |
86908053 |
RoHS Directive |
Correspondence |
Specific Gravity |
7.8 |
Hardness |
800HV |
Nominal Size (mm) |
15 mm |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Mitutoyo Corporation |
Product Code |
611625-02 |
Fracture Toughness |
12MPa・m1/2 |
Dimensional Tolerance (μm) |
±0.14 |
Bending Strength (MPa) |
1960 |
Dimensional Tolerance Width (μm) |
0.1 |
Height (mm) |
35 |
Thermal Expansion Coefficient (×10-7/℃) |
10.8±0.5 |
Width (mm) |
9 |
Young's Modulus (GPa) |
2.06E-2 |
Thermal Conductivity (W/mk) |
54.4 |
