Panasonic Gear Head Y Type 90 mm Size and 6 Reduction Ratio, MY9G6B

Name: Panasonic Gear Head Y Type 90 mm Size and 6 Reduction Ratio, MY9G6B
Brand: Panasonic
SKU: IND.GEA.739028608
Price: 10265 INR
Availability: InStock

Visit the Panasonic Store

EMI starts at ₹912/month. No Cost EMI available.

Available offers

Flat ₹400 off on Order above ₹10,000 | Valid for REPEAT Business User

View

Flat ₹800 off on Order above ₹20,000 | Valid for REPEAT Business User

View

Flat ₹200 off on Order above ₹6000 | Valid for REPEAT Business User

View

Flat ₹400 off on Order above ₹10,000 | Valid for NEW Business Users

View

Features

Applicable motor capacity (W)	60 or more
Allowable thrust load (N (kgf))	147[15]
Allowable overhang load (N (kgf))	588[60]
Structure (Bearing)	ball bearing

More Panasonic Gear Heads products More Gear Heads products

Warranty as Per Brand

100% Original Products

Secure Payments

100% Buyer Protection

Top Brands

specifications

Applicable motor capacity (W)	60 or more
Allowable thrust load (N (kgf))	147[15]
Allowable overhang load (N (kgf))	588[60]
Structure (Bearing)	ball bearing
Recommended Screw Tightening Torque (Nm (kgfcm))	2.94[30]
Suitable For	Induction motor 90mm M91Z60G4L / M91Z60G4Y / M91Z60GU / M91Z60G4GE / M91Z90G4L / M91Z90G4Y / M91Z90GU / M91Z9GE / M91Z60GK4L / M91Z60GK4Y / M91Z60GKU / M91Z60GK4GE / M91Z90GK4L / M91Z90GK4Y / M91Z90GKU / M91Z90GK4GE reversible motor 90mm M9RZ60G4L / M9RZ60G4Y / M9RZ60GU / M9RZ60G4GE / M9RZ90G4L / M9RZ90G4Y / M9RZ90GU / M9RZ90G4GE / M9RZ60GK4L / M9RZ60GK4Y / M9RZ60GKU / M9RZ60GK4GE / M9RZ90GK4L / M9RZ90GK4Y / M9RZ90GKU / M9RZ90GK4GE three-phase motor 90mm M9MZ60G4Y / M9MZ60GU / M9MZ60G4CE / M9MZ90G4Y / M9MZ90GU / M9MZ90G4CE / M9MZ60GK4Y / M9MZ60GKU / M9MZ60GK4CE / M9MZ90GK4Y / M9MZ90GKU / M9MZ90GK4CE motor with an electromagnetic brake 90mm M9RZ60GB4L / M9RZ60GB4Y / M9RZ60GBU / M9RZ60GB4GE / M9RZ90GB4L / M9RZ90GB4Y / M9RZ90GBU / M9RZ90GB4GE / M9MZ60GB4Y / M9MZ60GBU / M9MZ60GB4CE variable speed type induction motor 90mm M91Z60GV4L / M91Z60GV4Y / M91Z60GV4GE / M91Z90GV4L / M91Z90GV4Y / M91Z90GV4GE variable speed type reversible motor 90mm M9RZ60GV4L / M9RZ60GV4Y / M9RZ60GV4GE / M9RZ90GV4L / M9RZ90GV4Y / M9RZ90GV4 GE Variable Speed Type Unit Motor 90mm MUSN960GL / MUSN960GY / MUSN990GL / MUSN990GY / MUXN960GL / MUXN960GY / MUXN990GL / MUXN990GY
Transmission efficiency (%)	81
Mounting Screw	M6
Bearing Life	Standard: 10000 hours
Motor Type	Gear head
Mass (Kg)	1.4
Type	Y
Size (mm)	90
Monotaro ID	8632741
Type of Product	Gear Head
Reduction Ratio	6
Model No	MY9G6B
Import Country	Direct Import from Japan
Country of Origin	Japan
Name of Manufacturer/Packer/Importer	Panasonic Corporation
Included Components	M6 x 25 hexagon socket head cap screw
Specifications	With hinge
