| Type of Product | AC Gearmotor |
| Maximum Torque | 20 in-lb |
| Phase | Single |
| Part No | 453R96 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
AC Gearmotor |
Maximum Torque |
20 in-lb |
Phase |
Single |
Part No |
453R96 |
Frequency |
50/60 Hz |
Item Code |
453R96 |
Application |
Agriculture Conveyors Food and Beverage Equipment Industrial Machinery Packaging |
Housing Material |
Die Cast Aluminum |
Standard |
C-UL Recognized UL Recognized |
Output Shaft Diameter |
1/2 inch |
Motor Type |
Permanent Split Capacitor |
Thermal Protection |
None |
Maximum Ambient Temperature |
104°F |
Lubrication |
Grease |
Speed |
105 RPM |
Gear Ratio |
15.9:1 |
Mount Type |
Any Position |
Operating Voltage |
115 V AC |
Gear Material |
Nylon Sintered Steel |
Full Load Current (Amps) |
0.53 A |
Country of Origin |
USA |
Load Capacity |
50 ft-lb |
Output Shaft Length |
1-1/16 inch |
Bearing Type |
Ball on Motor Sleeve on Case |
Inverter Rated Watts |
Yes |
UNSPSC Code |
26101602 |
Length Less Shaft |
6.33 inch |
Rotation |
CW/CCW |
Seal Type |
Spring Loaded |
Mounting Orientation |
Any Angle |
Motor Enclosure |
Totally Enclosed Nonventilated |
Capacitor |
Yes |
Horse Power |
0.55 HP |
Shaft Orientation |
Parallel |
Gear Type |
Helical (1st Stage) Spur (Subsequent Stages) |
Brake Type |
None |
Output shaft |
1 |
Mount Hole Center-to-Center Width |
2.64 inch |
Overall Width |
3.36 inch |
Base to Center of Shaft |
2.07 inch |
Depth |
1/8 inch |
Overall Height |
3.5 Inch |
Mount Hole Center-to-Center Length |
2.64 inch |
Width |
3/16 inch |
Keyway Type |
Flat |
Compatible For |
2MDV4 Capacitor |
Overall Length |
6.99 inch |
Material Finish |
Powder Coated |
No Load Speed |
104 RPM |
Motor Insulation Class |
B |
Factor |
1 |
Starting Torque |
22 in-lb |
Width (mm) |
4.76 mm |
Overall Length (cm) |
17.75 cm |
Depth (mm) |
3.18 mm |
Overall Height (mm) |
88.9 mm |
Overall Width (mm) |
85.34 mm |
Maximum Torque (Nm) |
2.26 Nm |
