Ships within 90 days
Maximum Torque
Nameplate Speed
View
View
View
View
| Type of Product | DC Gearmotor |
| Maximum Torque | 250 inch-lb |
| Part No | 1LRA8 |
| Item Code | 1LRA8 |
Type of Product |
DC Gearmotor |
Maximum Torque |
250 inch-lb |
Part No |
1LRA8 |
Item Code |
1LRA8 |
Housing Material |
Die Cast Zinc |
Standard |
C-UL Recognized UL Recognized |
Output Shaft Diameter |
1/2 inch |
Motor Type |
Permanent Magnet DC |
Thermal Protection |
None |
Maximum Ambient Temperature |
40 °C |
Lubrication |
Grease Filled |
Gear Ratio |
525:1 |
Operating Voltage |
90 V DC |
Gear Material |
Cast Iron Output Gear Hardened Steel Worm Steel inchput Gear |
Country of Origin |
USA |
Output Shaft Length |
1-5/8 inch |
Bearing Type |
Porous Bronze Sleeve on Case Sleeve on Motor |
UNSPSC Code |
20101617 |
Rotation |
CW/CCW |
Seal Type |
Lip Type on Output Shaft |
Mounting Orientation |
Any Angle |
Motor Enclosure |
Totally Enclosed Nonventilated |
Shaft Orientation |
Right Angle |
Gear Type |
Worm |
Base to Center of Shaft |
2.63 inch |
Keyway Type |
Woodruff #404 |
Material Finish |
Unpainted |
Replaceable Brushes |
Yes |
Output Location |
Right Hand |
Nameplate Speed |
3 RPM |
Input Horsepower |
1/20 HP |
Overhung Load Capacity |
100 ft-lb |
Full Load |
0.59 A |
Shaft Type |
Keyed |
Maximum Torque (Nm) |
28.25 Nm |
