| Type of Product | AC Gearmotor |
| Maximum Torque | 50 in-lb |
| Phase | Single |
| Part No | 1LPU7 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
AC Gearmotor |
Maximum Torque |
50 in-lb |
Phase |
Single |
Part No |
1LPU7 |
Frequency |
50/60 Hz |
Item Code |
1LPU7 |
Housing Material |
Die Cast Zinc |
Standard |
C-UL Recognized CE Certified UL Recognized |
Output Shaft Diameter |
5/16 inch |
Motor Type |
Permanent Split Capacitor |
Thermal Protection |
None |
Maximum Ambient Temperature |
104°F |
Lubrication |
Grease Filled |
Speed |
7 RPM |
Gear Ratio |
239:1 |
Mount Type |
Any Position |
Operating Voltage |
115/230 V AC |
Gear Material |
Acetyl Steel |
Full Load Current (Amps) |
0.62/0.33 A |
Country of Origin |
USA |
Load Capacity |
50 ft-lb |
Output Shaft Length |
3/4 inch |
Bearing Type |
Ball on Motor Porous Bronze Sleeve on Case |
Inverter Rated Watts |
Yes |
UNSPSC Code |
20101617 |
Length Less Shaft |
6.13 inch |
Rotation |
CW/CCW |
Seal Type |
O-Ring Type on Output Shaft |
Mounting Orientation |
Any Angle |
Motor Enclosure |
Totally Enclosed Nonventilated |
Capacitor |
Yes |
Horse Power |
0.05 HP |
Shaft Orientation |
Parallel |
Brake Type |
None |
Output shaft |
1 |
Overall Width |
5.25 inch |
Base to Center of Shaft |
1.19 inch |
Overall Height |
3.94 inch |
Keyway Type |
Flat |
Material Finish |
Unpainted |
Motor Insulation Class |
B |
Length (mm) |
155.7 mm |
Overall Width (mm) |
133.35 mm |
Maximum Torque (Nm) |
5.65 Nm |
Load capacity (N) |
67.79 Nm |
