| Type of Product | DC Load Switching Relay |
| Model No | HH21UB-L AC100V |
| Mass (g) | About 92 |
| Terminal Shape | Plug-in terminal |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
DC Load Switching Relay |
Model No |
HH21UB-L AC100V |
Mass (g) |
About 92 |
Terminal Shape |
Plug-in terminal |
Return Voltage |
30% or more of the rated voltage |
Operating Temperature Range |
-20 to 40℃ (no freezing or condensation) |
Contact Configuration |
1B |
Function |
With operation indicator lamp |
Mechanical Durability |
5 million times or more |
Minimum Applicable Load |
DC24V, 20mA |
Suitable Sockets |
8GB, TP38S, TP38X |
Monotaro ID |
50200324 |
Operating Voltage |
80% or less of rated voltage |
Frequency (Hz) |
50/60 |
Contact Material |
Silver |
Power Consumption |
Approximately 3.3 VA (at 50Hz) |
Type of Sign |
Plugin |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Protection Class |
In a case |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Rated Coil Voltage |
AC 100 V |
Outer Dimensions |
36x36x68.2 mm |
