| Type of Product | Annunciator Relay |
| Model No | ADA1PA DC24V |
| Mass (g) | About 106 |
| Operating Temperature Range | -10 to 40℃ (no freezing or condensation) |
Type of Product |
Annunciator Relay |
Model No |
ADA1PA DC24V |
Mass (g) |
About 106 |
Operating Temperature Range |
-10 to 40℃ (no freezing or condensation) |
Mechanical Durability |
50 million times or more |
Minimum Applicable Load |
DC5V, 1mA |
Suitable Sockets |
Backside solder connection: 8GB, Front side screw connection: TP38S, Rail mounting type front side screw connection: TP38X, Vibration resistant metal: FX1B/FX1C |
Return Time (ms) |
25 or less |
Rated Carrying Current (A) |
3 |
Operating Time (ms) |
20 or less (however, 25ms for ADA1PE) |
Monotaro ID |
49984636 |
Power Consumption |
Approximately 2.4 W |
Withstand voltage (V / min) |
Between input and output: AC 2000, Between independent charging parts: AC 1000 |
Display Type |
Ⅰ |
Type of Sign |
Plugin |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
10-55Hz, double amplitude 1mm |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Rated Coil Voltage |
DC 24 V |
Insulation Resistance (MOhm) |
100 or more at DC 500V megger |
Allowable Fluctuation of Voltage |
85 to 110% of rated voltage |
Allowable Relative Humidity (%) |
95 or less |
