| Type of Product | RH1V Series |
| Model No | RH1V2-UAC120 |
| Terminal Shape | Printed Circuit Board Terminal |
| Contact Configuration | 1C |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
RH1V Series |
Model No |
RH1V2-UAC120 |
Terminal Shape |
Printed Circuit Board Terminal |
Contact Configuration |
1C |
Type |
Power Relay |
Rated Voltage (V) |
AC120 |
Monotaro ID |
6443745 |
Rated Current (mA) |
8.6(50Hz), 7.5(60Hz) |
Type of Sign |
Printed Board |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Protection Class |
In a case |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Contact Rated Control Capacity (Resistive Load) |
AC110V 10A/AC220V 7A/DC30V 10A |
Maximum Allowable Contact Current (A) |
10 |
