| Storage Temperature | -55 To +85°C (No Freezing) |
| Type of Product | SJ Series relay socket |
| Model No | SJ1S-07L |
| Mass (g) | About 30 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Storage Temperature |
-55 To +85°C (No Freezing) |
Type of Product |
SJ Series relay socket |
Model No |
SJ1S-07L |
Mass (g) |
About 30 |
Terminal Shape |
M3 ± Both Screws (Self-Up) |
Type |
Finger-Protection Screw Terminal Type |
Shock Resistance |
100G (when using release lever) |
Rated Carrying Current (A) |
12A |
No. of Pole |
1 |
Monotaro ID |
48020414 |
Rated Insulation Voltage (V) |
AC/DC250 V |
Withstand voltage (V / min) |
Between live metal parts and non-live metal parts: AC2000, between coil terminals and contact terminals: AC4000, between same polarity contact terminals: AC1000, between different polarity contact terminals: AC3000 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
Frequency 10 To 55 Hz, Double Amplitude 1.5 mm |
Protection Class |
Screw terminal: IP20 (IEC 60529) |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Operation Ambient Temperature (°C) |
-40 To +70°C (No Freezing) |
Recommended tightening torque range (Nm) |
1 Nm |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Specifications |
[Connectable Wire] Max. <Sup>2Mm2</Sup> |
Operating Ambient Humidity (% RH) |
5 To 85 (No Condensation) |
Storage Humidity (% RH) |
5 to 85 (no condensation) |
