| Storage Temperature | 5 to 85 (no condensation) |
| Type of Product | Ru Series Universal Relay |
| Model No | RU4S-A200 |
| Mass (g) | About 35 |
Storage Temperature |
5 to 85 (no condensation) |
Type of Product |
Ru Series Universal Relay |
Model No |
RU4S-A200 |
Mass (g) |
About 35 |
Terminal Shape |
Solder terminal |
Return Voltage |
30% or more (at 20 ℃ relative to the rated value) |
Contact Configuration |
4c |
Mechanical Durability |
50 million times or more |
Type |
Solder terminal type |
Rated Voltage (V) |
AC200/220 |
Maximum Continuous Applied Voltage |
110% (at 20 ℃ relative to the rated value) |
Contact Resistance |
less than 50 mΩ |
No. of Pole |
4 |
Monotaro ID |
6950693 |
Power Consumption (VA) |
AC：0.9 - 1.2(60Hz)/1.1 - 1.4(50Hz) |
Ambient Humidity to Use |
5% to 85% (with no condensation) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Protection Class |
In a case |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Operation Ambient Temperature (°C) |
-55 to 60 (no freezing) |
Insulation_Resistance (MΩ) |
100 or more (DC500V mega) |
Return Time |
20 ms or less |
