| Storage Temperature | -55 to 70 (no freezing) |
| Type of Product | Ry Miniature Relay |
| Model No | RY2S-UTAC240 |
| Terminal Shape | Solder terminal |
Storage Temperature |
-55 to 70 (no freezing) |
Type of Product |
Ry Miniature Relay |
Model No |
RY2S-UTAC240 |
Terminal Shape |
Solder terminal |
Return Voltage |
30% or more (initial value) [operating characteristics (at 20℃ against rated value)] |
Contact Configuration |
2c |
Type |
Miniature relay |
Minimum Applicable Load |
DC5V・10mA (reference value) |
Rated Voltage (V) |
AC240 |
Maximum Continuous Applied Voltage |
110% [operating characteristics (at 20℃ for rated value)] |
Contact Resistance |
less than 50 mΩ |
No. of Pole |
2 |
Monotaro ID |
6453572 |
Power Consumption (VA) |
About 1.1 (50Hz) ・ About 1 (60Hz) |
Contact Material |
Gold plating on Ag (pure silver) |
Rated Current (mA) |
4.9(50Hz), 4.3(60Hz)[±10%, (at20℃)] |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Protection Class |
In a case |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Operation Ambient Temperature (°C) |
-25 to 50 (no freezing) |
Insulation_Resistance (MΩ) |
100 or more (DC500V mega) |
Return Time |
20 ms or less |
