| Storage Temperature | -55 To 70°C (No Freezing) |
| Type of Product | RU Series universal relay |
| Model No | RU42S-A200 |
| Mass (g) | About 35 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Storage Temperature |
-55 To 70°C (No Freezing) |
Type of Product |
RU Series universal relay |
Model No |
RU42S-A200 |
Mass (g) |
About 35 |
Return Voltage |
30% or more (initial value) [operating characteristics (at 20℃ against rated value)] |
Mechanical Durability |
50 million times or more |
Type |
Twin Contact Type |
Minimum Applicable Load |
DC1V・0.1mA (reference value) |
Rated Voltage (V) |
AC200 - 220 |
Maximum Continuous Applied Voltage |
110% [operating characteristics (at 20℃ for rated value)] |
Contact Resistance |
Less Than 50 mΩ |
No. of Pole |
4 |
Monotaro ID |
48019310 |
Power Consumption (VA) |
0.9 - 1.2(60Hz), 1.1 - 1.4(50Hz) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
IDEC Corporation |
Operation Indicator |
Included |
Operation Ambient Temperature (°C) |
-55 To 60°C (No Freezing) |
Insulation_Resistance (MΩ) |
100 MΩ or more (DC500V mega) |
Return Time |
20 ms or less |
Specifications |
Designation Code: A200[Maximum Switching Frequency] Electrical: 1800 Times/Hour, Mechanical: 18000 Times/Hour |
Allowable Current (A) |
3 |
