| Series | MY-GS |
| Type of Product | General Purpose Relay |
| Coil Resistance | 160 Ohms |
| Contact Material | Silver (Ag) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Series |
MY-GS |
Type of Product |
General Purpose Relay |
Coil Resistance |
160 Ohms |
Contact Material |
Silver (Ag) |
Switching Voltage |
125 V DC, 250 V AC |
Contact Current Rating |
6 Amp |
Coil Type |
Non-Latching |
Coil Termination |
Plug In |
Contact Termination |
Plug In |
Relay Contact Form |
4 Form C (4PDT-NO, NC) |
Coil Voltage |
12 V DC |
Height |
36 mm |
Length |
28 mm |
Country of Origin |
India |
Coil Current |
75 mA |
Manufacturer Part Number |
MY4N-GS-R DC12 |
Name of Manufacturer/Packer/Importer |
Omron Automation and Safety |
Ordering ID |
653-MY4N-GS-RDC12 |
Data Sheet |
https://www.mouser.in/datasheet/3/39/1/my-gs_ds_e_10_1_csm1051922.pdf |
