| Type of Product | Servo Relay Unit |
| Model No | XW2Z-100J-A23 |
| Rated Voltage (V) | DC 24 |
| Monotaro ID | 46592953 |
Type of Product |
Servo Relay Unit |
Model No |
XW2Z-100J-A23 |
Rated Voltage (V) |
DC 24 |
Monotaro ID |
46592953 |
Suitable For |
[Driver] OMNUC W Series, SMARTSTEP Junior/A Series (Servo Relay Unit XW2B-20J6-3B R88D-WT, R7D-ZP/AP |
Rated Current (A) |
1 (temperature rise + 30 ℃ MAX) |
Withstand voltage (V / min) |
(Connector part) AC500 (Leakage current 1 mA or less) |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Protection Class |
IP00 IEC standard |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
0 to +55 |
Contact Resistance (ohm) |
(Connector part) 20 mΩ or less (20mV or less, 100mA or less) |
Insulation Resistance (MOhm) |
5 or more (at 500 V DC) |
Cable Length (m) |
1 |
Cable |
UL2464 interface cable |
Model of Suitable Main Unit |
CS1 customizable counter unit type CS1WHCP22-V1 special input / output (40-pin connector) unit |
Number of Axis |
2 Axes |
