Ships within 25 days
View
View
View
View
| Type of Product | Signal Relay |
| Model No | ATQ209 |
| Contact Configuration | 2c |
| Rated Voltage (V) | DC 5 |
Type of Product |
Signal Relay |
Model No |
ATQ209 |
Contact Configuration |
2c |
Rated Voltage (V) |
DC 5 |
Monotaro ID |
41225775 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Specifications |
Coil Voltage = 5 V DC Contact Arrangement = DPDT Mounting Type = Board Mount Terminal Type = Through Hole Maximum Switching Voltage AC = 125 V AC Maximum Switching Voltage DC = 110 V DC Length = 14mm Depth = 9mm Height = 5mm Dimensions = 14x9x5mm Operating temperature Min = -40°C UL/CSA/BSI. Relay TQ Series. Highly reliable signal switching relay Ultra-thin 5mm height Rated power consumption: 140mW and high sensitivity Au clad crossbar Twin contacts Automatic cleaning Possible sealing structure |
