| Type of Product | Liquid Level Relay Standard Set |
| Model No | TBL13FCS |
| Mass (g) | 1310 |
| Contact Configuration | 1C |
Type of Product |
Liquid Level Relay Standard Set |
Model No |
TBL13FCS |
Mass (g) |
1310 |
Contact Configuration |
1C |
Rated Voltage (V) |
AC250/DC24 |
Monotaro ID |
46751993 |
Material |
TBLR (3m) [Tetron] |
Rated Current (A) |
AC1.5/DC3 |
Applicable Standard |
Electrical Appliance and Material Safety Act/PSE mark |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Protection Class |
IP33 |
Name of Manufacturer/Packer/Importer |
Patlite Corporation |
Rating |
1c AC250V 1.5A, DC24V 3A (coil load) |
Specifications |
●Control range: 0.18 to 10m●Air pressure inside the tank: 1 atm |
Operating Temperature (c) |
-10 to 80 |
Durability |
Mechanical: 500,000 times or more, Electrical: 500,000 times or more |
Correction |
Nissui liquid level relay |
Minimum Load |
DC5V 160mA (reference value) |
Specific Gravity |
0.70 to 0.90 |
String Length (m) |
3 |
Set Contents |
TBLF3, TBLC208S, TBLR |
Specific Gravity Range |
0.70 to 0.90 |
Main Unit Material |
TBLF3 [Aluminum casting] |
