| Series | EMG REL |
| Type of Product | Relay Module |
| Contact Material | Silver Nickel (AgNi) |
| Switching Voltage | 250 V AC, 250 V DC |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Series |
EMG REL |
Type of Product |
Relay Module |
Contact Material |
Silver Nickel (AgNi) |
Switching Voltage |
250 V AC, 250 V DC |
Contact Current Rating |
6 Amp |
Mounting Style |
DIN Rail Mount |
Coil Type |
Non-Latching |
Coil Termination |
Screw |
Contact Termination |
Screw |
Relay Contact Form |
1 Form C (SPDT-NO, NC) |
Coil Voltage |
24 V AC |
Height |
75 mm |
Width |
22.5 mm |
Length |
75 mm |
IP Rating |
IP20 |
Country of Origin |
India |
Coil Current |
21 mA |
Manufacturer Part Number |
2951885 |
Name of Manufacturer/Packer/Importer |
Phoenix Contact |
Ordering ID |
651-2951885 |
Data Sheet |
https://www.mouser.in/datasheet/3/507/7/phoenix_contact_2951885_en.pdf |
RoHS Compliant |
Yes By Exemption |
