| Type of Product | Mid Range Relay |
| Coil Resistance | 320 Ohms |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Switching Voltage | 115 V AC, 28 V DC |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Mid Range Relay |
Coil Resistance |
320 Ohms |
Contact Material |
Silver Cadmium Oxide (AgCdO) |
Switching Voltage |
115 V AC, 28 V DC |
Contact Current Rating |
10 Amp |
Mounting Style |
Chassis Mount |
Coil Type |
Non-Latching |
Coil Termination |
Solder Hook |
Contact Termination |
Solder Hook |
Relay Contact Form |
2 Form C (DPDT-NO, NC) |
Coil Voltage |
28 V DC |
Height |
25.65 mm |
Width |
26.04 mm |
Length |
43.64 mm |
Country of Origin |
India |
Manufacturer Part Number |
FCA-210-1023M |
Name of Manufacturer/Packer/Importer |
TE Connectivity / AMP |
Ordering ID |
655-FCA-210-1023M |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=5-1773450-5_sec5_FCA-210&DocType=Catalog Section&DocLang=English&PartCntxt=2-1617749-0&DocFormat=pdf |
RoHS Compliant |
In Transition |
